The other configuration words for INP3 are explained in section (see following table).
X0
C.301
see
C.201
X100
C.302
„
C.202
XFail
C.313
„
C.213
Tfm
C.314
„
C.214
optional configuration 1
C.320
„
C.220
without linearization (Func1/2: 2)
10.6.3 Signal input 4 / INP4 (variable x3, ext. set-point Wext, override control ovc+/-)
The signal for three-element variable x3 or the galvanically isolated external set-point Wext or
the override control signal ovc+/- are configured with option p.c.b. C fitted in the controller
and the function selected during controller configuration.
The configuration words for INP4 are explained in section and (see following table).
Main configuration
C.350
see
C.300
X0
C.351
„
C.201
X100
C.352
„
C.202
Additional configuration
C.355
„
C.305
XFail
C.363
„
C.213
Tfm
C.364
„
C.214
Optional configuration 1
C.370
„
C.220
Optional configuration 2
C.371
„
C.221
C.372
„
C.222
Linearization table
. .
. .
C.387
C.237
10.6.4 Signal input 5 / INP5 (ratio variable x2, ext. set-point Wext)
The signal for ratio variable x2 or external set-point Wext is configured with option p.c.b. not fitted in
the controller and the function selected during controller configuration. The configuration words for
INP5 are explained in section and (see following table).
Main configuration
C.400
see
C.300
additional 0/2...10V (type: 32/33)
X0
C.401
„
C.201
X100
C.402
„
C.202
Additional configuration
C.405
„
C.305
XFail
C.413
„
C.213
Tfm
C.414
„
C.214
Optional configuration 1
C.420
„
C.220
without linearization (Func1/2: 2)
10.6.5 Signal input 6 / INP6 (auxiliary variable Yp, feedback Yp)
The signal for the auxiliary variable Yp or for the position feedbackk is configured, if this was
selected during controller configuration.
The configuration words for INP6 are explained in section and (see following table).
Main configuration
C.450
see
C.300
additional potentiometric transducer for Yp (type: 40)
X0
C.451
„
C.201
X100
C.452
„
C.202
Additional configuration
C.455
„
C.305
XFail
C.463
„
C.213
Tfm
C.464
„
C.214
Optional configuration 1
C.470
„
C.220
without linearisierung (Func1/2: 2)
