11.7 Control algorithm
Text 1 Description Range Default
CPara Controller parameters
Tpuls Min. pulse length 0.1 ... 999.9 s 0.3
Tm Actuator response time 10 ... 9999 s 30
Y2 Additional correcting value -105 ... 105 % 0
Ymin Min. correcting variable limiting -105 ... 105 % 0
Ymax Max. correcting variable limiting -105 ... 105 % 100
Y0 Correcting variable working point -105 ... 105 % 0
ParNr Actual parameter set 0 ... 3
Xsd2 Switching difference of additional contact 0.1 ... 999.9 1
LW Trigger point separation of additional contact -999 ... 9999 0
Xsd1 Switching difference of signaller 0.1 ... 999.9 1
Xsh2 Neutral zone (Xw > 0) 0.0 ... 999.9 % 0
Xsh1 Neutral zone (Xw < 0) 0.0 ... 999.9 % 0
Xsh Neutral zone 0.2 ... 999.9 % 0.2
Set 0 Parameter set 0
Xp1 0 Proportional band 1 0.1 ... 999.9 % 100
Xp2 0 Proportional band 2 0.1 ... 999.9 % 100
Tn1 0 Integral action time 0 ... 9999 s 10
Tv1 0 Derivative action time 0 ... 9999 s 10
T1 0 Duty cycle 1 0.4 ... 999.9 s 5
T2 0 Duty cycle 2 0.4 ... 999.9 s 5
Set1 Parameter set 1
Xp1 1 Proportional band 1 0.1 ... 999.9 % 100
Xp2 1 Proportional band 2 0.1 ... 999.9 % 100
Tn1 1 Integral action time 0 ... 9999 s 10
Tv1 1 Derivative action time 0 ... 9999 s 10
T1 1 Duty cycle 1 0.4 ... 999.9 s 5
T2 1 Duty cycle 2 0.4 ... 999.9 s 5
Set2 Parameter set 2
Xp1 2 Proportional band 1 0.1 ... 999.9 % 100
Xp2 2 Proportional band 2 0.1 ... 999.9 % 100
Tn1 2 Integral action time 0 ... 9999 s 10
Tv1 2 Derivative action time 0 ... 9999 s 10
T1 2 Duty cycle 1 0.4 ... 999.9 s 5
T2 2 Duty cycle 2 0.4 ... 999.9 s 5
Set3 Parameter set 3
Xp1 3 Proportional band 1 0.1 ... 999.9 % 100
Xp2 3 Proportional band 2 0.1 ... 999.9 % 100
Tn1 3 Integral action time 0 ... 9999 s 10
Tv1 3 Derivative action time 0 ... 9999 s 10
T1 3 Duty cycle 1 0.4 ... 999.9 s 5
T2 3 Duty cycle 2 0.4 ... 999.9 s 5
Recov Rapid Recovery (controller on)
XwOnY X-W limit value (X-W < XWony Ä Y tracking) 0 ... 9999 * ‘——’
XwOnX X-W limit value (X-W > XWonx Ä X tracking) 0 ... 9999 * ‘——’
GrwOn set-point gradient with X tracking active 0,01 ... 99,99 /min ‘——’
* Decimal point position of adjustment range as for main variable X1.
