11.2 Set-point function
Text 1 Description Range Default
Setpt Set-point parameter
LC+ Band width upper limit 0...9999 ‘——’ (switched off)
LC- Band width lower limit 0...9999 ‘——’ (switched off)
W0 lower set-point limit for Weff -999 ... 9999 0
W100 upper set-point limit for Weff -999 ... 9999 100
W2 additional set-point -999 ... 9999 100
Grw+ set-point gradient plus with W[w/min] 0.01 ... 99.99 ‘——’ (switched off)
Grw- set-point gradient minus with W[w/min] 0.01 ... 99.99 ‘——’ (switched off)
Grw2 set-point gradient with W2[w/min] 0.01 ... 99.99 ‘——’ (switched off)
11.3 Time function
Text 1 Description Range
Timer Timer-parameters
TS.Y Start value: Year 0...255
TS.MD Start value: Month and day Month:1...12; Day: 1...31
TS.HM Start value: Hour and minutes Hour:0...23; Minutes: 0...59
TE.Y Final value: Year 0...255
TE.MD Final value: Month and day Month:1...12; Day: 1...31
TE.HM Final value: Hour and minutes Hour:0...23; Minutes: 0...59
11.4 Programmer functions
Recp1 Programmer recipe 1
Analog Digital
Text 1 Description Range Def. Text 1 Description Range Def.
Wmode Change mode 0: Ramp 0 D0 Reset value control output 1..4 0000..1111 0000
1: Step Td1 Time segment 1 0...9999[min] ‘——’
2: Ramp (Time
priority
D1 control output 1..4 for segm. 1 0000..1111 0000
...
Pmode Preset mode 0: Segment start 1 Td20 Time segment 20 0...9999[min] ‘——’
1: Program time D20 controloutput1..4forsegm.20 0000..1111 0000
Pnext Successive program 1..3 or ‘——’ ‘— — ’
LC- Band width lower limit 0...9999 ‘——’
LC+ Band width upper limit 0...9999 ‘——’
Wp0 Reset value W0 -999...9999 0
TP1 Time segment1 0...9999 [min] ‘——’
WP1 Set-point segment 1 -999...9999 0
...
TP20
Time segment 20 0...9999 [min] ‘——’
WP20 Set-point segment 20 -999...9999 0
Recp2 see programmer recipe 1
Recp3 see programmer recipe 1
Parameters
Operating instruction KS94 38
