EMI Emissions:
Certified to EN50081-1:1992 and
EN50081-2:1994.
Safety Considerations:
Complies with EN61010-1:1993.
Supply Voltage:
90 - 264V AC 50/60Hz (standard)
20 - 50V AC 50/60Hz or 22 - 65V DC
(option)
Power Consumption:
4 watts approximately.
Front Panel Sealing:
To IP66 (NEMA 4).
A.10
PHYSICAL
Dimensions
Depth:
110mm (
1
16
-DIN controllers)
100mm (
1
4
-DIN &
1
8
-DIN controllers)
Front Panel - Width:
48mm (
1
16
-DIN &
1
8
-DIN controllers)
96mm (
1
4
-DIN controllers)
Height:
48mm (
1
16
-DIN controllers)
96mm (
1
4
-DIN &
1
8
-DIN controllers)
Mounting:
Plug-in with panel mounting fixing strap.
Panel cut-out:
45mm x 45mm (
1
16
-DIN controllers)
45mm x 92mm (
1
8
-DIN controllers)
92mm x 92mm (
1
4
-DIN controllers)
Terminals:
Screw type (combination head).
Weight:
0.21kg maximum
