Page 69: Ssr drive/ttl, Solid state, A.3 output 1
Maximum Input Delay
(OFF-ON):
1 second
Minimum Input Delay
(ON-OFF):
1 second
A.3
OUTPUT 1
General
Types Available:
Relay (as standard), SSR drive, solid state
and DC as options.
Relay
Contact Type:
Single pole double throw (SPDT).
Rating:
2A resistive at 120/240V AC.
Lifetime:
>500,000 operations at rated
voltage/current.
Isolation:
Inherent.
SSR Drive/TTL
Drive Capability:
SSR >4.2V DC into 1k
Ω
min. (
1
16
-DIN)
SSR > 4.3V into 250
Ω
min. (
1
4
-DIN &
1
8
-DIN)
Isolation:
Not isolated from input or other SSR drive
outputs.
Solid State
Operating Voltage Range:
20 - 280Vrms (47 - 63Hz)
Current Rating:
0.01 - 1A (full cycle rms on-state @ 25
°
C);
derates linearly above 40
°
C to 0.5A @
80
°
C.
Max. Non-repetitive Surge
Current (16.6ms):
25A peak
Min. OFF-State
dv
dt
@ Rated
Voltage:
500V/
µ
s
Max. OFF-State leakage @
Rated Voltage:
1mA rms
S054-A
