1
4
-DIN, 1
8
-DIN & 1
16
-DIN
TEMPERATURE CONTROLLERS
PRODUCT MANUAL
VOLUME 2
INSTALLATION & CONFIGURATION
INSTRUCTIONS
The procedures described in this Volume must be undertaken only
by technically-competent servicing personnel.
Contents - Volume 2
1 INSTALLATION 1-1
1.1 UNPACKING 1-1
1.2 PANEL-MOUNTING 1-1
1.3 CONNECTIONS AND WIRING 1-4
2 INTERNAL LINKS AND SWITCHES 2-1
2.1 REMOVING THE CONTROLLER FROM ITS HOUSING 2-1
2.2 REMOVING/REPLACING THE OUTPUT 2/OUTPUT 3 OPTION PCBs 2-3
2.3 REMOVING/REPLACING THE RS485 COMMUNICATIONS OPTION PCB
OR DUAL SETPOINT OPTION PCB 2-3
2.4 REPLACING THE CONTROLLER IN ITS HOUSING 2-3
2.5 SELECTION OF INPUT TYPE 2-4
2.6 SELECTION OF OUTPUT 1 TYPE 2-5
2.7 OUTPUT 2 TYPE/OUTPUT 3 TYPE 2-5
3 CONFIGURATION MODE 3-1
3.1 ENTRY INTO CONFIGURATION MODE 3-1
S056-V2 (i)
59125
