OPERATION
4
55
MFC 400
www.krohne.com 11/2013 - 4003221901 - AD MFC 400 FF R01 en
DECIMAL
Decimal (Point)
R The number of digits to the right of the decimal point which
should be used by an interface device in displaying the
specified parameter.
0
PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_
206 206 206 206
Conc. Vol.Flow 2
The measured value and status available to the Function
Block.
-
STATUS
Status
R Digital transducers, unlike their analogue versions, can detect
faults that make the measurement bad or prevent the
actuator from responding. This additional, valuable
information will be passed along with each transmission of a
data value in the form of a status attribute.
-
VALUE
Value
R A numerical quantity entered by a user or calculated by the
algorithm.
-
PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_ PRIMARY_VALUE_
RANGE_206 RANGE_206 RANGE_206 RANGE_206
Conc. Vol.Flow 2
Range
The high and low range limit values, the engineering units
code and the number of digits to the right of the decimal point
to be used to display the Primary Value.
-
EU_100
max value
R The engineering unit value which represents the upper end of
range of the associated Block Parameter.
NaN
EU_0
min value
R The engineering unit value which represents the lower end of
range of the associated Block Parameter.
-NaN
UNITS_INDEX
Units Index
R/W Device Description units code index for the engineering unit
descriptor for the associated block value.
m³/h
Settings:
Volume flow units: Volume flow units: Volume flow units: Volume flow units:
m³/s; m³/min; m³/h; m³/d; L/s; L/min; L/h; L/d; kL/s; kL/min;
kL/h; kL/d; mL/min; CFS; CFM; CFH; ft³/d; kCFS; kCFM;
kCFH; kft³/d; cm³/s; cm³/min; cm³/h; cm³/d; gal/s; GPM;
gal/h; gal/d; kgal/s; kgal/min; kgal/h; kgal/d; bbl/s; bbl/min;
bbl/h; bbl/d; ImpGal/s; ImpGal/min; ImpGal/h; ImpGal/d
DECIMAL
Decimal (Point)
R The number of digits to the right of the decimal point which
should be used by an interface device in displaying the
specified parameter.
0
CONC_CONC_ CONC_CONC_ CONC_CONC_ CONC_CONC_
ENABLE ENABLE ENABLE ENABLE
Concentration
R Concentration measurement enabled. 0:Off
Settings:
0:Off / 1:On
CONC_DATA_SEL CONC_DATA_SEL CONC_DATA_SEL CONC_DATA_SEL
Conc. Data Sel.
R/W Select the set of general concentration parameters are active
(Fct. C2.1).
0:Conc. Data 1
Settings:
0:Conc. Data 1 / 1:Conc. Data 2
CONC1_CCF01 CONC1_CCF01 CONC1_CCF01 CONC1_CCF01
CONC1_CCF01
R/W Defines the whether the concentration measurement use the
linear or non-linear coefficients (Fct. C2.4.1).
0:Linear
Settings:
0:Linear / 1:Non Linear
CONC1_CCF02 CONC1_CCF02 CONC1_CCF02 CONC1_CCF02
CONC1_CCF02
R/W Density of product A (Fct. C2.4.2). 0.0 g/cm³
Settings:
-9.0E7…9.0E7 g/cm³
CONC1_CCF03 CONC1_CCF03 CONC1_CCF03 CONC1_CCF03
CONC1_CCF03
R/W Temperature coefficient for product A (Fct. C2.4.3). 0.0
Settings:
-9.0E7…9.0E7
CONC1_CCF04 CONC1_CCF04 CONC1_CCF04 CONC1_CCF04
CONC1_CCF04
R/W Temperature coefficient squared for product A (Fct. C2.4.4). 0.0
Settings:
-9.0E7…9.0E7
Parameter Parameter Parameter Parameter
DD name Access Description and settings Initial Value
