KROHNE MFC 400 FOUNDATION FIELDBUS - Manual (Page 14)

4
OPERATION
14
MFC 400
www.krohne.com 11/2013 - 4003221901 - AD MFC 400 FF R01 en
FD_CHECK_MAP FD_CHECK_MAP FD_CHECK_MAP FD_CHECK_MAP
Check Map
R/W This parameter enables or disables conditions to be detected
as active for this alarm category.
(24) (25) (26) (27)
(9)
Setting:
(00) Check / (01) Electronics : Operation Info /
(02) Config: NoMeas.Value / (08) Electronics : Power Fail /
(09) Process: System Control / (10) Configuration : Totaliser /
(11) Process : Signal Low / (12) Process : 2 Phase Flow /
(13) Process : Signal Search / (14) Electronics : IO
Connection / (15) Process : Current input / (16) M Process /
(17) M Configuration / (18) M Electronics / (19) M Sensor /
(20) S Process / (21) S Configuration / (22) S Electronics /
(23) S Sensor / (24) C Process / (25) C Configuration /
(26) C Electronics / (27) C Sensor / (28) F Process /
(29) F Configuration / (30) F Electronics / (31) F Sensor
FD_CHECK_MASK FD_CHECK_MASK FD_CHECK_MASK FD_CHECK_MASK
Check Mask
R/W This parameter allows the user to suppress any single or
multiple conditions that are active, in this category, from
being broadcast to the host through the alarm parameter.
(24) (25) (26) (27)
(9)
Setting:
(00) Check / (01) Electronics : Operation Info /
(02) Config: NoMeas.Value / (08) Electronics : Power Fail /
(09) Process: System Control / (10) Configuration : Totaliser /
(11) Process : Signal Low / (12) Process : 2 Phase Flow /
(13) Process : Signal Search / (14) Electronics : IO
Connection / (15) Process : Current input / (16) M Process /
(17) M Configuration / (18) M Electronics / (19) M Sensor /
(20) S Process / (21) S Configuration / (22) S Electronics /
(23) S Sensor / (24) C Process / (25) C Configuration /
(26) C Electronics / (27) C Sensor / (28) F Process /
(29) F Configuration / (30) F Electronics / (31) F Sensor
FD_CHECK_PRI FD_CHECK_PRI FD_CHECK_PRI FD_CHECK_PRI
Check Priority
R/W This parameter allows the user to specify the priority of this
alarm category.
0
Setting:
0...15
FD_FAIL_ACTIVE FD_FAIL_ACTIVE FD_FAIL_ACTIVE FD_FAIL_ACTIVE
Fail Active
R This parameter reflects the error conditions that are being
detected as active as selected for this category. It is a bit
string, so that multiple conditions may be shown. See section
2.9.
Uninitialized
Setting:
(00) Check / (01) Electronics : Operation Info /
(02) Config: NoMeas.Value / (08) Electronics : Power Fail /
(09) Process: System Control / (10) Configuration : Totaliser /
(11) Process : Signal Low / (12) Process : 2 Phase Flow /
(13) Process : Signal Search / (14) Electronics : IO
Connection / (15) Process : Current input / (16) M Process /
(17) M Configuration / (18) M Electronics / (19) M Sensor /
(20) S Process / (21) S Configuration / (22) S Electronics /
(23) S Sensor / (24) C Process / (25) C Configuration /
(26) C Electronics / (27) C Sensor / (28) F Process /
(29) F Configuration / (30) F Electronics / (31) F Sensor
FD_FAIL_ALM FD_FAIL_ALM FD_FAIL_ALM FD_FAIL_ALM
Fail Diagnostic Alarm
This parameter is used primarily to broadcast a change in the
associated active conditions, which are not masked, for this
alarm category to a Host System.
-
Unacknowledged R/W A discrete enumeration which is set to "Unacknowledged"
when an alarm occurs, and set to "Acknowledged" by a write
from a human interface device or other entity which can
acknowledge that the alarm/event has been noticed.
Uninitialized
Setting:
Uninitialized / Acknowledged / Unacknowledged
Parameter Parameter Parameter Parameter
DD name Access Description and settings Initial Value
