OPERATION
4
21
MFC 400
www.krohne.com 11/2013 - 4003221901 - AD MFC 400 FF R01 en
FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_
MAP_18 MAP_18 MAP_18 MAP_18
FD_EXTENDED_
MAP_18
R/W Field Diagnostics of "M Electronics" (31) (30) (29)
Setting:
(29) Backplane Difference / (30) Factory Data Faulty / (31)
Backplane Data Faulty
FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_
MAP_19 MAP_19 MAP_19 MAP_19
FD_EXTENDED_
MAP_19
R Field Diagnostics of "M Sensor" Uninitialized
Setting:
(00) Reserved
FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_
MAP_20 MAP_20 MAP_20 MAP_20
FD_EXTENDED_
MAP_20
R/W Field Diagnostics of "S Process" (31) (30) (28) (27)
Setting:
(27) Velocity Out of Range / (28) Prod.Density Out of Range /
(30) Flow Out of Range / (31) Proc.Temp.Out of Range
FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_
MAP_21 MAP_21 MAP_21 MAP_21
FD_EXTENDED_
MAP_21
R/W Field Diagnostics of "S Configuration" Uninitialized
Setting:
(03) IO B Overrange Binary Output / (04) IO B Overrange
Current Output / (05) IO B Overrange Current In-/Output /
(06) IO A Overrange Binary Output / (07) IO A Overrange
Current Output / (09) IO A Overrange Current In-/Output
FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_
MAP_22 MAP_22 MAP_22 MAP_22
FD_EXTENDED_
MAP_22
R/W Field Diagnostics of "S Electronics" (26)
Setting:
(26) Electr.Temp.Out of Spec
FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_
MAP_23 MAP_23 MAP_23 MAP_23
FD_EXTENDED_
MAP_23
R Field Diagnostics of "S Sensor" (31)
Setting:
(31) Temp. Or Strain Res. Def.
FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_
MAP_24 MAP_24 MAP_24 MAP_24
FD_EXTENDED_
MAP_24
R Field Diagnostics of "C Process" Uninitialized
Setting:
(00) Reserved
FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_
MAP_25 MAP_25 MAP_25 MAP_25
FD_EXTENDED_
MAP_25
R/W Field Diagnostics of "C Configuration" (31) (30) (29) (28)
Setting:
(07) IO B Sim. Binary Output / (08) IO B Sim. Current In-
/Output / (09) IO B Sim. Limit Sw./Current Out /
(10) IO A Sim. Binary Output / (11) IO A Sim. Current In-
/Output / (12) IO A Sim. Limit Sw./Current Out /
(22) Fieldbus Sim. Active / (28) Sensor Starting up /
(29) Sensor Simulation Active / (30) Sensor in Standby Mode /
(31) Sensor in Stop Mode
FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_
MAP_26 MAP_26 MAP_26 MAP_26
FD_EXTENDED_
MAP_26
R Field Diagnostics of "C Electronics" Uninitialized
Setting:
(00) Reserved
FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_
MAP_27 MAP_27 MAP_27 MAP_27
FD_EXTENDED_
MAP_27
R Field Diagnostics of "C Sensor" Uninitialized
Setting:
(00) Reserved
FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_ FD_EXTENDED_
MAP_28 MAP_28 MAP_28 MAP_28
FD_EXTENDED_
MAP_28
R Field Diagnostics of "F Process" Uninitialized
Setting:
(00) Reserved
Parameter Parameter Parameter Parameter
DD name Access Description and settings Initial Value
