OPERATION

MFC 400

www.krohne.com

11/2013 - 4003221901 - AD MFC 400 FF R01 en

UNITS_INDEX

Units Index

R/W

Device Description units code index for the engineering unit

descriptor for the associated block value.

Depends on the

type, the device is

calibrated for

Temperature units:

K; °C; °F

Mass flow units:

kg/s; kg/min; kg/h; kg/d; t/s; t/min; t/h; t/d; g/s; g/min; g/h;

g/d; lb/s; lb/min; lb/h; lb/d; klb(US)/s; klb(US)/min; klb(US)/h;

klb(US)/d; STon/s; STon/min; STon/h; STon/d; LTon/s;

LTon/min; LTon/h; LTon/d

Density units:

kg/m³ / kg/dm³ / kg/L / g/m³ / g/L / g/cm³ / g/ml / Mg/m³ /

t/m³ / lb/in³ / lb/ft³ / lb/gal / lb/ImpGal

Volume flow units:

m³/s; m³/min; m³/h; m³/d; L/s; L/min; L/h; L/d; kL/s; kL/min;

kL/h; kL/d; mL/min; CFS; CFM; CFH; ft³/d; kCFS; kCFM;

kCFH; kft³/d; cm³/s; cm³/min; cm³/h; cm³/d; gal/s; GPM;

gal/h; gal/d; kgal/s; kgal/min; kgal/h; kgal/d; bbl/s; bbl/min;

bbl/h; bbl/d; ImpGal/s; ImpGal/min; ImpGal/h; ImpGal/d

Speed (velocity) units:

m/s; mm/s; m/h; km/h; in/s; ft/s; yd/s; in/min; ft/min; yd/min;

in/h; ft/h; yd/h

Concentration units:

% / degAPI / degPlato / degBrix / Baume 144 / Baume 145 /

% NaOH / % mass A / % mass B / % mass / % vol A / % vol B /

% vol / % alc by mass / % alc by vol

Units for Drive Level, Sensor Average, Sensor Deviation, 2

Phase Signal:

Frequency units:

Strain units:

Ohm

DECIMAL

Decimal

R/W

The number of digits to the right of the decimal point which

should be used by an interface device in displaying the

specified parameter.

Parameter

Parameter
DD name

Access

Description and settings

Initial Value
