Section 4
Conductivity Set Up
4.00
General Set Up
The conductivity set up options include settings for all the functions that are relevant
for the conductivity channel only. Functions that can be set in these menus are
calibration settings, alarm settings, endpoint stability and ATC/temperature settings.
Adjustments made to these are stored in non-volatile memory so will not need to be
re-entered unless further changes are required. They will also be retained regardless
of the power connection to the instrument.
4.01
Connect the power supply as described in section 2.2.3. It is not necessary to
connect the probes for the set-up procedures.
4.02
Switch on the power at the supply socket; then press the power on/off key on the
instrument.
4.03
The 3540 start up screen is shown for a few seconds followed by the main
measurement
screen with either the pH or conductivity tab highlighted (depending on
which was active when power was switched off).
4.04
Press the right or left arrow keys [ ] to highlight the Set Up tab on the menu bar at
the bottom of the screen. This will open the main Set Up page.
Main Set Up screen
4.05
Press the up or down arrow keys [ ] to move the highlight over the Conductivity
Set Up… option. Press the enter key [ ] to open the Conductivity Set Up page.
Conductivity Set Up screen
Use the Conductivity Set Up flow diagram and Conductivity Set Up menu selections
on the following pages to identify the settings that you wish to adjust from their default
values. Then refer to the following paragraphs for further guidance on making these
adjustments.
