USING TDG LOGGER
This application can display and log total dissolved gas and temperature
readings from In-Situ’s T506 TDG probe.
1. Connect the T506 to the RuggedReader’s 9-pin serial port.
2. On the RuggedReader, tap Start > Programs > TDG Logger.
The TDG Logger application will launch,
and in a moment device readings will be
displayed. Allow a few minutes for the
readings to stabilize.
To record (log) readings, you must first specify
a site. The Record button is dimmed out
(unavailable) until a site is entered.
To enter a site:
1. Tap the down arrow beside the site box.
2. Select .
SECTION 6: IN-SITU SOFTWARE
2
1
