3 USING THE HARDWARE
This chapter describes the hardware components of the RuggedReader:
• Buttons
• Power Management: suspending, powering off, and resetting the
RuggedReader
• Stylus
• Touchscreen
• LEDs signals
• Peripheral Devices (CF and SD cards, USB drives)
BUTTONS
The following chart shows the names and functions of each button on the
keypad.
