10

0055450 rev. 002 10/07

Rugged

Reader

Operator’s Manual

SECTION 1: INTRODUCTION

20 Stylus
21 Main screws (do not remove)
22 Top cap screws (captive) (page 32)
23 Slot for future accessory
24 Compact Flash card slot (page 32)
25 Secure Digital I/O card slot (page 32)
26 Stylus slot
27 USB Client (mini B)
28 12V DC jack
29 9-pin serial port
30 USB Host (mini A)
31 Cable routing channel

Top view with top cap

20

22

23

24

25

26

Top view without top cap

Communications module

26

27

28

29

30

31

20

21
