GDS-806/810/820/840 Programming Manual

77

Use serial poll or the *STB? Query to read the contents of the SBR. The bits in the

SBR are set and cleared depending on the contents of the Standard Event Status

Register (SESR), the Standard Event Status Register (SESR), and the Output

Queue.

Standard Event Status Register (SESR): Table 5-4 shows the SESR

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

PON

USR

CME

EXE

DDE

QYE

NU

OPC

128

64

32

16

8

4

2

1

Table 5-4: Standard Event Status Register (SESR)

The bit 0 (OPC, Operation Complete) shows that the operation is complete. This bit

is active when all pending operations are complete following an *OPC command.

The bit 1 is always zero.

The bit 2 (QYE, Query Error) indicates a command or query protocol error. The bit 3

(DDE, Device Error) shows that a device error occurred.

The bit 4 (EXE, Execution Error) shows that an error occurred while the

oscilloscope was execution a command or query.

The bit 5 (CME, Command Error) shows that an error occurred while the

oscilloscope was paring a command or query.

The bit 6 (USR, User Request) is ignored here for this oscilloscope.

The bit 7 (PON, Power On) shows that the oscilloscope was powered on.

Use the *ESR? Query to read the SESR. Reading the SESR clears the bits of the

registers so that the register can accumulate information about new events.
