GDS-806/810/820/840 Programming Manual

6

SR0 (Service Request): The oscilloscope has no SRQ (Service request)

function.

RL2 (Remote/Local):

The oscilloscope will ignore the LLO (local lockout)

command.

PP0

(Parallel

Poll):

The oscilloscope has no Parallel Poll interface

function.

DC1 (Device Clear):

The oscilloscope has Device clear capability to return

the device to power on status.

DT0 (Device Trigger):

The oscilloscope has no Device Trigger interface

function.

C0 (Controller) : This oscilloscope can not control other devices.

The GPIB address setting

To change the GPIB address, please use the following steps:

z Press

the

UTILITY button on the front panel. The utility menu provides

Interface Menu sub menu by pressing F2 softkey which GPIB sub menu is

included. Press F1 softkey to select GPIB setting menu.

For GPIB sub menu

z Type GPIB: Select GPIB port.

z Addr 1~30: select the appropriate address for GPIB.

z Previous Menu: back to previous menu.
