GDS-806/810/820/840 Programming Manual
32
:CHANnel:SCALe
Sets or query the vertical scale of the specified channel.
Syntax
:CHANnel:SCALe
:CHANnel:SCALe?
Arguments
→Specify the channel number (1|2)
is the desired gain value in volts per division. The range is 2mV/div to 5V/div
(with 1X probe).
Next table shows the relationship between the value and matching scale.
0.002 Æ2mV 0.01 Æ10mV 0.1 Æ100mV 1 Æ1V
0.005
Æ2mV
0.02
Æ20mV
0.2
Æ200mV
2
Æ2V
0.05
Æ50mV
0.5
Æ500mV
5
Æ5V
Returns
Examples
:CHANnel1:SCALe 1 , setup the channel one at 1V per division.
