GDS-806/810/820/840 Programming Manual

48

:TEMPlate:DOWNload?

(Available for firmware 2.0 and above only)

Download the user-selected template.

Syntax

:TEMPlate1:DOWNload?

Arguments

→Specify the template number (1|100)

Returns

Format:

The string of data is following.

# Data size digit

Data

size

Package

type

Template

number

Position

Text

string

Reserved

Check

sum

Template

data

#: Begin of data string.

Data size digit: Indicate the digits of following data string amount (1 digit), The

value is ‘3’ in ASCII code.

Data size: The amount of current data string (3 digits). The value is “548” in ASCII

code.

Package type: The GO/NO-GO template package type (1 bytes). The value is

0x03 in hex.
