p. 30 SFG-830

(2) Negative Attenuator Calibration

To calibrate the negative attenuator, you should go through Calibration Number 9
~ 16 in turn, and perform the following 3 steps for each number.
n Set the Calibration Number.
o Use a DMM (FLUKE-8842) at DCV range to measure the output.
p Key in an appropriate Calibration Value to make the output to be the particular

value listed below:

n

Calibration Number

p

Output should be :

9

-39

± 0.1mV

10

-78

± 0.5mV

11

-156

± 1mV

12

-312

± 1mV

13

-625

± 2mV

14

-1.25V

± 10mV

15

-2.5V

± 10mV

16

o

Use a DMM (FLUKE-8842) at

DCV range to measure the

output

-5V

± 10mV

(3) Carrier Null Calibration

n Set the Calibration Number to 17.
o Use a distortion meter (DM-155 A/B) to measure the output.
p Key in an appropriate calibration value to minimize the distortion. Then go

through step

q

~

t

repeatedly to calibrate the output of Number 18 ~ 113.

q Set the Calibration Number (18 ~ 113, one number each time).
r Use a spectrum analyzer to measure the output.
s Set the Center Frequency of the spectrum analyzer to be X, where

X

Calibration Number

=

×

+

(

)

17

312500 1000 .

t Key in an appropriate Calibration Value to minimize the power of frequency Y,

where

Y

X

=

2

.

(4) Calibrating the Amplitude of Sine Wave

n Set the Calibration Number 114 ~ 115 (one number each time).
o Use a DMM (FLUKE-8842) at ACV range with 50 ohm load to measure the

output.

p Input an appropriate Calibration Value until the output to be the corresponding

figures as listed in the table below. Then go through step

q

~

s

repeatedly to

calibrate the output of Number 116~307.

q Set the Calibration Number 116 ~ 307 (one number each time).
r se a measuring receiver (HP-8902A or equivalent for high frequency amplitude

checks) at ACV range to measure the output.

s Input an appropriate Calibration Value to make the output to be as follows:

Calibration Number 114~307

Output Voltage

odd

1.77

± 0.005Vrms

even

3.54

± 0.01Vrms
