SFG-830 p.7
Sample Rate 42.949600MHz/N, N=8, 10, 12,…2 15
Waveform Length 12,000 points max.
Arbitrary
Waveforms
Vertical Resolution 12 bits
Sweep Function Line or Log
Sweep Range 20mHz ~ 30MHz Sweep
Sweep Time 0.01S ~ 1000S
AM Modulation
Function
External, Internal
(sine, triangle, ramp, square)
Modulation Rate
10mHz ~ 10kHz (Internal)
50kHz (max. external)
Modulation Span 0 ~ 100%
Ext. Input
±5V for 100% modulation
Ext. Input Impedance 100 k
Ω
FM Function Sine, Triangle, Ramp, Square
Modulation Rate 10mHz ~ 10kHz
Modulation Span 30mHz (100kHz for triangle, ramp)
PSK Span 360 degrees
Modulation
Modulation Rate 20Hz ~ 10kHz
Interface
RS232
GPIB interface (optional)
Arbitrary waveform composer software for Windows(optional)
Accessories GTL-101
× 1, Instruction Manual × 1
Power Source 100/120/220/ 240V AC
±10%, 50/60Hz
Dimensions 214 (W)
× 89 (H) × 370 (D) mm
Weight Approx. 5kg
