SFG-830 p.13
p Press [ SHIFT ] and [ ] to make the right-hand figures “2047” blinking; then
key in [ 0 ] and press [ Hz ] to change the value of the first point from 2047 to 0.
q Press [ SHIFT ] and [ ] again to make the left-hand figures “0001” blinking.
r Press [ ] to compile the second point.
ª The display will show “0002 -2047”, which indicates the value of the second
point is -2047. The number “0002” is blinking.
s Press [ SHIFT ] and [ ] to make “-2047” blinking; then key in [ 4 ], [ 0 ], [ 0 ],
and press [ Hz ] to change the value of the second point from -2047 to 400.
t Repeat step q to s to complete the compilation of other points.
u Press [ FREQ ] and set the reading frequency according to the frequency
setting procedure.
The limitations of input:
(1) Compiling points: up to 12000 points
(2) Compiling value : -2047 ~ +2047
(3) Reading frequency : 42.949600MHz/N, where N=8, 10, 12…2
15
6.6 Deleting the Data of Arbitrary Wave
n Press [ SHIFT ] and [ ARB ].
ª The display will show “arb edit”, then shifts to compiling mode.
o Press [ SHIFT ] and [ ARB ] again.
ª The display will show “clr arb fnc”, then shifts to the mode of deleting arbitrary
wave.
p Press any unit-button.
ª The display will show “arb cleared” for a few seconds, then shows “clr arb
fnc”, which indicates that all the data of the arbitrary wave have been deleted.
q Press [ SHIFT ] and [ ARB ] to compile again.
6.7 The Setting of STOR Button
The STOR button is used to save the setup parameters of the instrument into its
memory; numbers can be selected from 0 to 9, i.e., up to 10 groups.
n Push [ STOR ] button.
o Key in a number from 0 to 9 to indicate the number .
p Press any button from [ DEG/ % ], [ mHz/dBm ], [ kHz/Vrms ], or [ Hz/Vpp ] to
complete.
Example: To save a parameter to the RAM of group #5, press [ STOR ] first. Then key in [ 5 ] and
press [ Hz ].
