p. 28 SFG-830

7.6 Adjusting the Filter

n Press [Shift] + [DEFAU] keys
o Set conditions:

Function : ARB

Amplitude : 8Vp-p

Frequency : 2MHz (sampling frequency)

p Use a oscilloscope at 2V/DIV, 200ns/DIV with 50 ohm load to measure the

output.

q Adjust SVC301, 302, 303, and 304 in turn to get the shortest rise time and the

smallest peak to peak ripple.

r Repeat steps n~q once.

7.7 Adjusting Harmonic Distortion

n Set conditions:

Function : Sine Wave

Amplitude : 8Vp-p

Frequency : 15kHz

o Use a spectrum analyzer with 50 ohm load, start frequency at 0Hz and stop

frequency at 15kHz, to measure the output.

p Adjust SVR501 until get the smallest second harmonic (20kHz).
q Repeat step n and o.
r Adjust SVR603 until third harmonic (45kHz) and fifth harmonic (75kHz)

achieve the same level.

NOTE : When use software in calibrating , these steps should be gone through after Callier Null

calibration. Meanwhile, adjust SVR501 and SVR603 to minimize distortion.

7.8 Calibrating by Software

(A) Calling Default Calibration Data

n Press [Shift], [9], [8],[3], [0] keys.

ª The display will indicate “default” for a few seconds, then shows 1000.00Hz.

The calling of default calibration data is then finished.

(B) Manual Calibration

Basic Steps :
n Press [Shift], [0], [8], [3], [0] keys to shift to the manual calibration mode.

ª The display will indicate “CAL EDIT” for a few seconds, then shows 00001

(blinking) and 1000. The figures on the left side represent the Calibration
Number, and the right-hand figures are the corresponding Calibration Value.
The blinking area is where you can input figures, and can be switched by
pressing the [ ] and [ ] keys in FUNCTION column.
