p. 14 SFG-830
6.8 The Setting of RECL Button
The RECL button can retrieve the parameters saved in the RAM.
n Push [ RECL ] button.
o Key in the number of the group that you want to retrieve the parameters from.
p Select a button from [ DEG/ % ], [ mHz/dBm ], [ kHz/Vrms ], or [ Hz/Vpp ] to
complete.
Example: To recall a parameter from the memory of group #5, press [ RECL ] first. Then key in
[ 5 ] and press [ Hz ].
6.9 The SHIFT Key and Function Keys
SHIFT button is used to enable the secondary function of certain function keys
that with blue symbols printed above. The SHIFT LED will be on after pressing
the [ SHIFT ] button. At this time, only the buttons with blue symbols are workable.
To release the SHIFT function, press [ SHIFT ] again.
™ The Secondary Functions
1. [ SHIFT ] + [ SWP CF ] Displays sweep center frequency.
2. [ SHIFT ] + [ DEFAU ] Gets back to the default status of SFG-830.
3. [ SHIFT ] + [ ARB ] Sets up arbitrary-wave compiler.
4. [ SHIFT ] + [ DATA ] Displays the last 256 byte of ASCII data received
by SFG-830.
5. [ SHIFT ] + [ GPIB ] Sets up GPIB on/off status by using the arrows
buttons in MODIFY column.
6. [ SHIFT ] + [ ADDR ] Sets up GPIB address (range from 0 to 30).
7. [ SHIFT ] + [ LOCAL ] Switches RMT status to LOCAL status.
8. [ SHIFT ] + [ RS232 ] Sets up RS232 on/off status and its BAUD RATE.
9. [ SHIFT ] + [ ] Switches the blinking state between the number
and the value of a point for inputting data while
compiling the arbitrary wave.
10. [ SHIFT ] + [ ] Switches the blinking state between the number
and the value of a point for inputting data while
compiling the arbitrary wave.
