GDS-2000 Series Programming Manual

69

:TEMPlate:MAX

Sets and query the number of template used for maximum boundary.

Before running this command, the oscilloscope has to be initialized as “Normal

Template” mode, please add the command of “:TEMPlate:MODe 0” in order to
change the settings.

Syntax

:TEMPlate:MAX {0|20}

:TEMPlate:MAX?

Arguments

0→ Ref A

1~20→ Internal memory W1~W20

Returns

Note: A template can be defined as either MAX or MIN template only.

Note B: Before input any template editing commands, the oscilloscope has to be initialized,

please add the command of “:GONogo:FUNCtion 1” in order to initial the oscilloscope.
