background image

GDS-2000 Series Programming Manual

35

:CHANnel:OFFSet

Sets or query the offset voltage.

Syntax

:CHANnel:OFFSet

:CHANnel:OFFSet?

Arguments

→Specify the channel number (1|2|3|4)

is the desired offset value in volts. The range is dependent on the scale and

the probe attenuation factor. The offset ranges are following:

Offset Range:

2mV/div ~ 50mV/div

±

0.5V

100mV/div ~ 500mV/div

±

5V

1V/div ~ 5V/div

±

50V

Next table shows the relationship between the value and matching offset

voltage.

2.00E-3Æ2mV

1.00E-2Æ10mV

1.00E-1Æ100mV

1.00E+0Æ1V

5.00E-3Æ5mV

2.00E-2Æ20mV

2.00E-1Æ200mV

2.00E+0Æ2V

5.00E-2Æ50mV

5.00E-1Æ500mV

5.00E+0Æ5V

Returns
