GDS-2000 Series Programming Manual
67
:REF:LOCate
Adjust the position of reference waveform Ref A ~ D.
Syntax
:REF:LOCate
:REF:LOCate?
Arguments
→ Specify the location of reference waveform (1|2|3|4)
1→ Ref A 2→ Ref B
3→ Ref C 4→ Ref D
between 100 ~ -100
Returns
:REF:SAVe
Save input waveform as reference waveform Ref A ~D
Syntax
:REF:SAVe {1|2|3|4|5}
Arguments
→ Specify the location of reference waveform (1|2|3|4)
1→ Ref A 2→ Ref B
3→ Ref C 4→ Ref D
SAVe {1|2|3|4|5}→ Specify the input waveform source
1|2|3|4→ channel 1~4. 5→ Math
Example
:REF1:SAVe 2 Save channel two’s waveform as reference waveform A.
