background image

GDS-2000 Series Programming Manual

29

:ACQuire:MEMory? (query only)

Transfer the total waveform data from the acquisition memory. (The memory

capacity can be selected as 500, 5000, 12500, or 25000 points. See Page 28 for

details.)

Syntax

:ACQuire:MEMory?

Arguments

→Specify the channel number (1|2|3|4)

Returns

The string of data is following.

#

Data size digit

Data size

The time

duration

between two

adjacent

sampling

points

Channel indicator Reserved data

Waveform data

#: Begin a transmission of data string.

Data size digit: Indicate the digits of following data string amount (1 digit).

Data size: the amount of current data string (4, or 5 digits). Next table lists the

relations between data size digit, data size and record length.

Data String

Record length

Begin a

transmission of

data string

Data size

digit

Data size

Record length=500

#

4

1008

The rest of data

Record length=5000

#

5

10008

The rest of data

Record length=12500

#

5

25008

The rest of data

Record length=25000

#

5

50008

The rest of data
