PSM-SERIES PROGRAMMABLE POWER SUPPLY
USER MANUAL
⎯ ⎯
43
5-4. The maximum value of the output setting
Model PSM-2010 PSM-3004 PSM-6003
Output Range
Item
8V,20A 20V,10A 15V,7A 30V,4A 30V,6A 60V,3.3A
Output Voltage 8.240V 20.60V 15.450V 30.900V 30.900V 61.800V
Output Current 20.60A 10.30A 7.210A 4.120A 6.180A 3.400A
OVP (Over Voltage
Protection
22V 32V 64V
OCP (Over Current
Protection
22A 7.500A 6.500A
Step Voltage 8.000V 20.000V 15.000V 30.000V 30.000V 60.000V
Step Current 20.00A 10.00A 7.000A 4.000A 6.000A 3.300A
Delay Time 59’59.9”
Memory Group 100
PSM-SERIES PROGRAMMABLE POWER SUPPLY
USER MANUAL
⎯ ⎯
44
5-5. Test Lead
Table 1:
Model PSM-2010 PSM-3004 PSM-6003
Test Lead
GTL-104 or GTL-204
(The maximum current: 10A)
Note: The attached test lead to the PSM-SERIES is only used for the front
panel output terminal with the maximum current of 10A.
Table (2)
AWG 10 12 14 16 18 20 22 24 26 28
Maximum
Current(amps)
40 25 20 13 10 7 5 3.5 2.5 1.7
mΩ/m 3.3 5.2 8.3 13.2 21.0 33.5 52.8 84.3 133.9 212.9
