PSM-SERIES PROGRAMMABLE POWER SUPPLY
USER MANUAL
⎯ ⎯
37
2) Store the present setting status to the memory bank:
Press [SHIFT][STORE], set the panel operation to Storing setting
selection, input the memory address by using number key (When
want to correct the input value due to error key-in, can use wheel
knob to clear the error value and re-input the value), then press
[ENTER] to complete the change of store, and the panel will
display “DONE” message.
3) Recall the setting status from the memory bank:
Press [SHIFT][RECALL], set the panel operation to Recall
setting, use the number key to recall the desired memory address
(When want to correct the input value due to error key-in, can use
wheel knob to clear the error value and re-input the value), then
press [ENTER] to complete the change, and the panel will
display “DONE” message.
z Auto Running Operation
The function must be used together with the DELAY setting which
is defined as the operation delay time of next running operation. The
Delay function is workable only under Auto Running operation.
1) Delay time setting:
Press [DELAY] to set the panel operation to Delay time setting
selection.
PSM-SERIES PROGRAMMABLE POWER SUPPLY
USER MANUAL
⎯ ⎯
38
2) The setting and store of very group of data:
A group setting includes the Output range, Output voltage value,
Output current value, Over Voltage protection level, Over
Current protection level, Over Voltage status (ON/OFF), and
Delay time. User can proceed the setting and store it to the
memory bank group by group up to 100 groups maximum.
3) Recall range setting (Auto running operation range):
Regarding the setting description, please refer to AUTO RANGE
operation.
4) Enter AUTO mode by pressing [AUTO], now, the operation is in
the auto running function by pressing [OUTPUT].
5) Under this mode, press [SHIFT][AUTO INFO] can monitor the
current operation setting address and operation time.
