CONFIGURATION
97
C
ONFIGURATION
Acquisition Select acquisition mode .................................. 99
Select waveform memory length .................... 101
Real time vs Equivalent time sampling mode 103
Display Select waveform drawing (vector/dot) ........... 104
Accumulate waveform ................................... 105
Set display contrast....................................... 106
Freeze the waveform ..................................... 106
Select display grid ......................................... 107
Turn Off menu .............................................. 107
Horizontal Move waveform position horizontally ............ 108
Select horizontal scale .................................. 109
Set the horizontal expansion mode ............... 110
Select horizontal scaleSelect waveform update
mode ............................................................ 111
Zoom waveform horizontally ......................... 114
Show waveform in X-Y mode ......................... 115
