QUICK REFERENCE
49
Default Settings
Here is the factory installed panel setting which
appears when pressing the Save/Recall key→F1
(Default Setup).
Save/Recall
Default
Setup
F 1
Acquisition Mode: Normal Memory length: 500
Hor. Expand: Center
Channel Scale: 2V/Div CH1: On, CH2/3/4: Off
Coupling: DC Invert: Off
BW limit: Off Probe attenuation: x1
Expand: Ground
Cursor Source: CH1 Horizontal: None
Vertical: None
Display Accumulate: Off Graticule:
Go-NoGo Go-No: Off Source: CH1
Violating: Stop
Horizontal Scale: 2.5us/Div Mode: Main
Math Type: + (Add) Channel: CH1+CH2
Position: 0.00 Div Unit/Div: 2V
Math Off
Measure Source1, 2: CH1, CH2 Type: VPP, Avg, Freq,
Duty Cycle, Risetime
Program Mode: Edit Step: 1
Trigger Type: Edge Source: Channel1
Mode: Auto Slope:
Coupling: DC Rejection: Off
Noise Rejection: Off
Utility Square wave probe, 1k,
50% duty cycle Hardcopy: save image,
ink saver on
Sound: Off Interface: USB
