MEASUREMENT

93

Edit: Source

Procedure

1. Press the Utility key.

Utility

2. Press F5 (More) twice.

More

F 5

x2

3. Press F3 (Data Logging).

Data

Logging

F 3

4. Press F2 (Source) repeatedly

to select the source channel
(CH1/2/3/4 or math).

Source

CH1

F 2

Edit: Setup Parameters

Background

The type of data that will be logged
(waveform/image/both), the capture interval time
and the duration of the data logging must first be
set before logging function can be used.

Procedure

1. Press the Utility key.

Utility

2. Press F5 (More) twice.

More

F 5

x2

3. Press F3 (Data Logging).

Data

Logging

F 3

4. Press F3 (Setup).

Setup

F 3
