QUICK REFERENCE

31

Horizontal menu key

HORI

MENU

Main

F 1

Window

F 2

Window

Zoom

F 3

XY

F 5

Hor.MENU

Roll

F 4

Select main (default) display

F1→TIME/DIV

Select Window mode and zoom

F2→TIME/DIV , F3

Select windows roll mode

F4→TIME/DIV

Select XY mode

F5→VOLTS/DIV

Math key (1/2)

MATH

Operation

+

F 1

CH1+CH2

F 2

Position

0.00 Div

F 4

Unit/Div

2V

F 5

MATH

-12div ~ +12div

CH1+CH2/
CH3+CH4

Select math operation (+/–/x)

F1

Select channel combination

F2

Set result position

F4→VAR

Math result vertical scale

F5→VOLTS/DIV
