Go-NoGo Test
Overview
Background The Go-NoGo test checks if a waveform fits inside
a user-specified maximum and minimum
amplitude boundary (template). The test result is
communicated in three ways: the display (menu
contents), buzzer sound, and pulse signal output
from the rear panel terminal.
Test parameters item default setting setup details
Buzzer sound when
the test fails (NoGo) Off page79
NoGo criteria: in or
out of the boundary Out page79
Test signal Channel 1 page80
Test continue or stop
when NoGo occurs Stop page80
Boundary (template)
– select minimum and
maximum as separate
waveforms or create
both boundaries from
a single waveform Min/Max
separately page81
Default setting To recall the default setting,
press the Save/Recall key, then
press F1 (Default Setup). See
page49 for details.
Save/Recall
Default
Setup
F 1
