57
10.2 Creating a new Task
There may be no tasks in the Calibrator's database when you want to run a task. You can create a new task via "New
Task Wizard" or download them from the special calibration software.
According to different instruments,there are five types of task: RTDs (Resistance Temperature Detector), TC
(Thermocouples), Loop Instruments, Flow (Delta‐Pressure and Flow Meters), Pressure Instruments.
To start your task management pressTask in Basic Mode. Select Task List in Task Management page and press Enteror
Select. On theTask List page, you can create a new task, delete task and run it.
Press New on Task List page, and the New Task Wizard will appear. You can move the cursor by pressing the navigation
keys, press ENTER orthe Select toselect a task.
An example shows how to create a RTD transmitter instrument task and run it.
Editing UUT General Data
After the RTD Transmitteris selected, press Enter or Select to enter the New Task General Data page.In this page, you
can input the general information of the UUT.
Editing UUT Input Data
The Input Quantity defines which fields are required. Common fields for all quantities are: Input Quantity (Parameters),
Unit and Range. On this page, you should select an available RTD Sensor Type (as shown in Figure 10.2).
In addition, there may be some additional information: Pressure unit (for pressure instruments), decimals (flow
instruments), temperature unit (for RTDs/thermocouples) and cold junction compensation temperature (for
thermocouples).
Editing UUT Output Data
