Table of Contents
- 5 -
POWER REAM
Page
Safety Information……………………………………………………….. 3
Specifications………………………………………………………………… 6
Installation…………………………………………………………………….. 7
I/O Configuration………………………………………………………….. 10
Robot Programming………………………………………………………. 12
Operation………………………………………………………………………. 15
Feature Setups………………………………………………………………. 16
Automatic I/O Configuration…………………………………………. 18
Maintenance and Troubleshooting………………………………… 19
Diagnostics…………………………………………………………………….. 20
Parts Replacement………………………………………………………… 21
Pneumatic Diagram………………………………………………………. 29
Electrical Diagram…………………………………………………………. 30
Parts Diagram………………………………………………………………… 32
Optional Accessories……………………………………………………… 35
