46
¾
Disabled, 2 Sectors, 4 Sectors, 8 Sectors, 16 Sectors
(default value)
LBA Mode Control
When enabled, this option uses 28-bit addressing of he hard
drive without regard for cylinders, heads, and sectors.
Note that Logical Block Access may decrease the access speed
of the hard disk.
In order to make changes to this field, the Type field must be set
to User. Configuration options are:
¾
Disabled, Enabled (default value)
32 Bit I/O
When enabled, this option speeds up communication between
the CPU and the IDE controller. This option supports PCI local
bus only. ISA bus is not supported. Set the Type field to Auto
to provide the optimum transfer mode. Configuration options
are:
¾
Disabled, Enabled (default value)
Transfer Mode
When enabled, this option speeds up communication between
the system and the IDE controller by using enhanced I/O
transfer modes (PIO) Modes.
Set the Type field to Auto to provide the optimum transfer mode.
Configurations are:
¾
Standard, Fast PIO 1, Fast PIO 2, Fast PIO 3, Fast
PIO 4, FPIO 3 / DMA 1, FPIO 4 / DMA 2
Ultra DMA Mode
When enabled, this option speeds up data transfer to and from
the drive. In order to make changes to this field, the Type field
must be set to User.
Set the Type field to Auto to provide the optimum transfer mode.
Configurations are:
