86
on its adjacent side as shown on the
illustration.
WARNING: Be sure to loosen all the screws first
before removing it totally to release the heatsink.
Failure to do so will cause a major damage to the
heatsink.
2. Now you can totally remove all the screws also in that
order when you first loosen the screw.
To insert the heatsink, follow the procedures below:
1. Make sure it is in slant position aligning with the socket of
the compartment.
2. Slowly push down and insert the heatsink into its socket
until it is properly seated into the expansion compartment.
3. Be certain that the screw holes on the heatsink align
completely with the screw holes in the compartment.
4. Secure the screw one at a time and on the adjacent side.
5. You can now tighten up the screws after all are secured
into place one at a time and on the adjacent side.
