6-3 6-4
IM 11Y01B01-01E-A 6th Edition :Feb 13, 2013-00
<6. BASIC OPERATION>
Display Text Description
Line 1 - Measurement O2 xx.x % Measured gas and unit of measurement For Gas 1
and/or Gas 2 as configured
moisture xx.x ppm
Line 2 – Transmission or
Second Gas Measurement Transmission xx.x % Laser light transmission strength
(0-100% range)
CH4 xx.x % Second measurement gas and unit
Line 3 - Status
Initializing…… shown during the power-up and
initialization of the analyzer
System OK Normal Operation condition with no active alarms
WARNING Det Sig Low
WARNING Trans Low
WARNING Spectr Noise
WARNING Gas Pres
WARNING Gas Temp
WARNING Gas Level
WARNING Board Temp
WARNING Conditions
FAULT Laser Temp
FAULT Det Sig High
FAULT Det Sig Lost
FAULT Peak Response
FAULT Peak Center
FAULT Conditions
Zero Calibrating…
Span Calibrating…
Offline Validating…
Online Validating… Validation Status
Data Transferring…
Transfer Success
Transfer Failure
Data Transfer Status
Line 4 - Information
Yokogawa TDLS
SN 76-1xxx-05-xx
AO1: CONC xx-xx%/ppm/ppb/mg/m3
or mg/Nm3
AO2: TRANS xx-xx%
AO3: TEMP xx-xxF/C/K
10.0.0.35
TEMP Act/Con/Fox xx F/C/K
PRES Act/Con/Fix xx.x PsiA/BarA/KPa/
torr/atm
OPL xx.x in/ft/cm/m
Launch xx deg C
Detect xx deg C
Analyzer Name
Analyzer Serial No.
Configured 4-20mA output for AO1, AO2, & AO3
Static IP Address
Process Gas Temperature used for gas
concentration calculation
Process Gas Pressure used for gas
concentration calculation
Optical Path Length over which the analyzer is
measuring the target gas
Launch unit internal temperature
Detect unit internal temperature
Online Menu Level 1 Menu Level 2 Menu Level 3 Menu Level 4 Menu Level 5 Menu
Trends Refresh Refresh Current Trend screen
Gas 1 Concentration
STDEV of Gas 1 Concentra-
tion*
Gas 2 Concentration*
STEV of Gas 2 Concentration*
Transmission*
Laser Temp Setpoint*
Laser Temp in DegC*
Peak Center Position*
Gas Temperature*
Gas Pressure*
*(Similar to Gas 1 Concentration)
Min
Max
Minutes
