6-3
IM 11Y01B01-01E-A 6th Edition :Feb 13, 2013-00
<6. BASIC OPERATION>
Online Menu Level 1 Menu Level 2 Menu Level 3 Menu Level 4 Menu Level 5 Menu
ADVANCED
*Password
Protected
Configure Laser Spectra & Control Peak Width
Control Mode Manual
Automatic
Max Current
Laser Temp Set*
*(similar to Max Current)
Current
New
Spectrum Capture
LTSP Limits Low
High
fast Update Enable/Disable
Calibration
Data
Offline Calibration Zero Calibraton Manual pres, temp opl, gas, type, conc
Automatic Local Initate
Remote Initiate: control channel
Time Initate: frequency
Settings: valve, purge, tiime, AO
mode gastype, conc, opl, temp,
pres
Restore Old Calibration
Factory Calibration
Zero Offset Current
New
Span Calibration Manual
Automatic Local Initiate
Remote Initiate: control channel
Time Initiate: frequency
Settings: conc, opl, temp, pres
Restore Old Calibration
Factory Calibration
Transmission
Pres, temp, opi, gas, type, conc
Dark Current
Peak Search Peak with Lower WL
Opeak with Higher WL
All Peaks
Result Display
Offline Validation Validation Gas 1
Validation Gas 2*
Two Gas Validation *
*(similar to Gas 1)
Manual
Automatic Local Initate
Remote Initate: control channel
Time Initiate: frequency
Settings: conc, opl, temp, pres,
gastype, valve,purgetimes, AO
mode
Online Validation Check Gas 1
Check Gas 2*
*(similar to Gas 1)
Manual Local Initate
Remote Initate: control channel
Time Initiate: frequency
Settings: conc, opl, temp, pres,
gastype, valve,purgetimes, AO
mode
Clear Validation Alarms
Alarm History
Automatic
Cal History
Spectrum Capture Manual
Automatic Updated
Relative
Absolute
Warning
Fault
