Manual Title: Model TDLS200 Tunable Diode Laser Spectroscopy Analyzer
Manual Number: IM 11Y01B01-01E-A
Edition Date Remark (s)
1 st April 2008 Newly Published
2 nd April 2009 Revisions: Formatting was corrected.
3 rd April 2010 Revisions:
General specifications, page 3, were added to the document, and
dimensional drawings were added.
4 th August 2011 Revisions:
Dimensional drawings in section 5.9 were corrected and updated.
Caption titles and figure numbers were added to all figures within
the document. Page 4 and page 5
specifications were added.
5th Feburary 2012 Revisions:
1. Quick start section 1 was modified.
2. Section 2 added note about area classification.
3. Section 2.1 corrected the power range statement.
4. Data plate information in section 2.2 was updated.
5. Section 4.3 corrected Figure 7 valve relay diagram, updated
Field terminal block indications.
6. Section 4.6 Added process Interface option.
7. Reformated Section 5 & updated area classification
information. Added Seciton 5.12
8. Updated software basic structure information.
9. Deleted section 7.3 Analog Signal field Loop check, and made
section 7.5 Validation and Calibration its own Section, now
becoming Section 8.
10. Removed section 8.3.1 & 8.4
11. Removed Sections 4.10-4.13
Revision Record
6th February 2013 Revisions:
1. Updated General Specifications Section3
2. Updated KC Mark information and data plate labels in section
2.2 instrument check.
