i

IM 01C25R01-01E

Revision Information

Title

: EJX910A and EJX930A

Multivariable Transmitters

Manual No. : IM 01C25R01-01E

Edition

Date

Page

Revised Item

1st

May 2005

New publication

2nd

June 2006

1-1

2-7

3-3

3-5

3-6

7-1

7-3

10-1

10-3

10-6

10-8 and 10-9

10-11

Add information for F

OUNDATION

fieldbus protocol type.

Add comments for fieldbus in ‘NOTE’

2.5.2

Correct errors in the formula.

Correct errors in Table 2.8

3.9

Add WARNING for fieldbus and external temperature input cable.

3.9.3

Add CENELEC ATEX intrinsically safe type.

3.10

Correct errors.

3.11

Revise information for PED.

3.12

Section added.

7.1

Add note for fieldbus type in ‘IMPORTANT’ notice.

7.5.1

Add (2)Intrinsically Safe Type.

10.1

Add information and note for fieldbus type.

Add information of L capsule.

Delete information related to the auto compensation function.

10.2

Add code for F

OUNDATION

fieldbus type, L capsule, bottom process

connection and a braket.

10.3

Add /KS2, /T12 and /PE3.

10.4

Add dimensions for bottom process connection.

Add note for fieldbus type.

3rd

Feb. 2008

General

2-4 to 2-7

3-3 to 3-7

3-7

10-2 and 10-4

10-5

10-7 and 10-8

10-10 and 10-11

Change of the style code.

Change the figure of amplifier housing.

2

Remove FSA210 and add FSA120.

3.9

Add applicable standard and cerfiticate number for each approval.

3.9.4

Add IECEx flameproof type (/SF2).

10.1

Remove FSA210 and add FSA120.

10.2

Add new suffix codes for 316 SST blind plugs and brackets.

10.3

Add /KS25 and /SF2.

10.4

Revise external dimensions.

4th

Aug. 2008

3-8

10-7

10-8

3.10

Add caution for EMC.

10.3

Add /FS15.

10.3

Add the description of Process Sealing Certification to /CF1.

5th

Mar. 2009

3-6

Add model EJX930A.

3.9.3

Add /KU2.

6th

Aug. 2009

10-5 to 10-7

10-8 to 10-10

10-12 to 10-14

10.2

Revise material statement.

10.3

Add optional code /KU21 and /A1.

10.4

Correct the dimension of the cable gland with 1/2 NPT connections.

7th

Apr. 2010

2-5

3-1

3-4 to 3-9

7-4 to 7-6

9-11

10-4

10-8 to 10-9

10-10

10-12 to 10-14

2.5

Add Unit for Device Revision 2.

3.3

Add limitation of ambient temperature for /HE.

3.9

Add limitation of ambient temperature for /HE.

7.6.1

Change the figure of cable gland.

9.5.3

Add ILBD alarms.

10.1

Add material for cover O-rings.

10.3

Add limitation of ambient temperature for /HE.

10.3

Add /HE and /DG6.

10.4

Correct the dimension of the cable gland with M20 connections.
