10. General Specifications
10.1 Standard Specifications
Refer to IM 01C25R03-01E for F
OUNDATION
Fieldbus communication type marked with“◊”.
Performance Specifications
See General Specifications sheets:
EJX910A: GS 01C25R01-01EN
EJX930A: GS 01C25R04-01EN
Functional Specifications
Span and Range Limits
Differential Pressure (DP)
EJX910A
Measurement
Span/Range
kPa
inH
2
O(/D1)
mbar(/D3)
mmH
2
O(/D4)
L
Span
0.1 to 10
0.4 to 40
1 to 100
10 to 1000
Range
-10 to 10
-40 to 40
-100 to 100 -1000 to 1000
M
Span
0.5 to 100
2 to 400
5 to 1000
50 to 10000
Range -100 to 100 -400 to 400 -1000 to 1000
-10000 to
10000
H
Span
2.5 to 500
10 to 2000
25 to 5000
0.025 to 5
kgf/cm
2
Range -500 to 500 -2000 to 2000 -5000 to 5000 -5 to 5 kgf/cm
2
EJX930A
Measurement
Span/Range
kPa
inH
2
O(/D1)
mbar(/D3)
mmH
2
O(/D4)
M
Span
1 to 100
4 to 400
10 to 1000
100 to 10000
Range -100 to 100 -400 to 400 -1000 to 1000
-10000 to
10000
H
Span
5 to 500
20 to 2000
50 to 5000
0.05 to 5
kgf/cm
2
Range -500 to 500 -2000 to 2000 -5000 to 5000 -5 to 5 kgf/cm
2
Static Pressure (SP)
Absolute Pressure
EJX910A
Measurement
Span/Range MPa abs
psia(/D1)
bar abs(/D3)
kgf/cm
2
abs
(/D4)
L
Span
1 to 16
145 to 2300
10 to 160
10 to 160
Range
0 to 16
0 to 2300
0 to 160
0 to 160
M
H
Span
1 to 25
145 to 3600
10 to 250
10 to 250
Range
0 to 25
0 to 3600
0 to 250
0 to 250
EJX930A
Measurement
Span/Range MPa abs
psia(/D1)
bar abs(/D3)
kgf/cm
2
abs
(/D4)
M
H
Span
1 to 32
145 to 4500
10 to 320
10 to 320
Range
0 to 32
0 to 4500
0 to 320
0 to 320
Gauge Pressure (Sealed gauge)
EJX910A
Measurement
Span/Range
MPa
psi(/D1)
bar(/D3)
kgf/cm
2
(/D4)
L
Span
1 to 16
145 to 2300
10 to 160
10 to 160
Range
-1 to 16
-14.5 to 2300
-10 to 160
-10 to 160
M
H
Span
1 to 25
145 to 3600
10 to 250
10 to 250
Range
-0.1 to 25 -14.5 to 3600
-1 to 250
-1 to 250
EJX930A
Measurement
Span/Range
MPa
psi(/D1)
bar(/D3)
kgf/cm
2
(/D4)
M
H
Span
1 to 32
145 to 4500
10 to 320
10 to 320
Range
-0.1 to 32 -14.5 to 4500
-1 to 320
-1 to 320
External Temperature (ET) (PT100 ohm)
Measurement External
Temperature Span/Range
°C
°F
K
L
M
H
Span
10 to 1050
18 to 1890
10 to 1050
Range
-200 to 850
-328 to 1562
73 to 1123
Fixed Temperature -273 to 1927 -459 to 3500
0 to 2200
