<10. General Specifications>
10-15
IM 01C25R01-01E
Unit : mm (approx.inch)
Bottom Process Connection Type
(Installation code B)
12
(0.47)
39
(1.54)
129 (5.08)
Zero
adjustment
Ground
terminal
ш78(3.07)
ш70 (2.76)
117*
1
(4.61)
54
(2.13)
188(7.40)
109 (4.29)
Low
pressure
side
High
pressure
side
Process connector
(optional)
Conduit
connection
Mounting
bracket
(optional)
95(3.74)
219(8.62)
79
(3.11)
Conduit
connection
(for RTD)
2-inch pipe
(O.D. 60.5 mm)
Integral indicator
(optional)
110 (4.33)
Vent plug
Shrouding bolt*
2
Electrical connection code 2
External temp. input code 1, 2, 3, and 4
Electrical connection code 9
External temp. input code 0
Electrical connection code 4
External temp. input code 1, 2, 3, and 4
Electrical connection code 2 and 4
External temp. input code B, C, and D
54
(2.13)
6
(0.24)
48
(1.89)
F1006.ai
69(2.72)
116(4.57)
Cable Gland
105(4.13)
58(2.28)
Cable Gland
*1: When Option code K1, K2, K5, or K6 is selected, add 30 mm(1.18 inch) to the value in the figure.
*2: Available only when specifying the option code including ATEX, IECEx or TIIS flameproof type.
