<10. General Specifications>
10-13
IM 01C25R01-01E
Item
Description
Code
Material certificate *
8
Cover flange
*9
M01
Cover flange, Process connector
*10
M11
Pressure test Leak test
certificate *
11
Test Pressure: 16 MPa (2300 psi)
*12
Nitrogen (N
2
) Gas
*14
Retention time: one minute
T12
Test Pressure: 25 MPa (3600 psi)
*13
T13
Test Pressure: 32 MPa (4500 psi)
*21
Nitrogen (N
2
) Gas or Water
*20
Retention time: one minute
T09
*1:
Not applicable with color change option.
*2:
Applicable for Wetted parts material code S.
*3:
The unit of MWP (Max. working pressure) on the name plate of a housing is the same unit as specified by option codes D1, D3, and
D4.
*4:
Applicable for vertical impulse piping type (Installation code 7) and Wetted parts material code S.
*5:
Applicable for output signal codes E and J. The hardware error indicates faulty amplifier or capsule.
*6:
Applicable for wetted parts material code S; process connection codes 3, 4, and 5; installation code 9; and mounting bracket code
N. Process connection faces on the other side of zero adjustment screw.
*7:
Also see ‘Ordering Information’.
*8:
Material traceability certification, per EN 10204 3.1B.
*9:
Applicable for process connections codes 0 and 5.
*10: Applicable for process connections codes 1, 2, 3, and 4.
*11: The unit on the certificate is always Pa unit regardless of selection of option code D1, D3 or D4.
*12: Applicable for EJX910A capsule code L.
*13: Applicable for EJX910A capsule codes M and H.
*14: Pure nitrogen gas is used for oil-prohibited use (option codes K1, K2, K5, and K6).
*15: Applicable for output signal code -F.
*16: Applicable for measurement span code M and H. If compliance with category III is needed, specify this code.
*17: 316 or 316L SST. The specification is included in amplifier code 2. Not applicable for external temperature input code -1, -2, -3 and
-4.
*18: This option code must be specified with option code EE.
*19: The change of pressure fluctuation is monitored and then detects the impulse line blockage. See TI 01C25A31-01E for detailed
technical information required for using this function.
*20: Pure nitrogen gas or pure water is used for oil-prohibited use (option codes K1, K2, K5, and K6).
*21: Applicable for EJX930A.
