<10. General Specifications>
10-2
IM 01C25T04-01EN
10.2 Optional Specifications
For items other than those described below, refer to each User’s Manual.
Item Description Code
Data configuration at factory Software Damping CD
10.3 Optional Specifications (For Explosion Protected type)
Item Description Code
Factory Mutual (FM) FM Explosionproof *1 FF1
FM Intrinsically safe and Nonincendive *1 —
ATEX ATEX Flameproof *1 KF22
ATEX Intrinsically safe [Ex ia] *1 KS26
ATEX Intrinsically safe [Ex ic] *1 KN26
Canadian Standards
Association (CSA)
CSA Explosionproof *1 CF1
CSA Intrinsically safe *1 —
IECEx Scheme IECEx Flameproof *1 SF2
IECEx Intrinsically safe *1 —
Contact Yokogawa representative for the codes indicated as ‘-’.
*1: Applicable for Electrical connection code 2, 4, 7, 9, C and D .
< Factory Setting >
Tag Number (Tag plate) As specified in order
Software Tag (TAG) ‘PT1001’ unless otherwise both Tag Number and Software Tag
specified in order
Bus Address ‘0x7E(126)’ unless otherwise specified in order
Output Mode (Characterization Type) ‘Linear’ unless otherwise specified in order
Calibration Range (Scale In Lower/Upper Value) As specified in order
Calibration Range Unit Selected from mmH
2
O, mmH
2
O(68°F), mmHg, Pa, hPa, kPa,
MPa, mbar, bar, gf/cm 2 , kgf/cm 2 , inH
2
O, inH
2
O(68°F), inHg, ftH
2
O,
ftH
2
O(68°F) or psi. (Only one unit can be specified)
Output Scale (Out Scale Lower/Upper Value) ‘0 to 100%’ unless otherwise specified.
Software Damping (Filter Time Const) *1 ‘2 s’ or as specified in order
*1: To specify this item, /CD option is required.
