<9. Parameter Lists>
9-6
IM 01C25T04-01EN
Relative
Index
Index
Parameter
Write
Mode
Initial Value
Explanation
176
192
TEST_16
—
—
Not used for the transmitter
177
193
TEST_17
—
—
Not used for the transmitter
178
194
TEST_18
—
—
Not used for the transmitter
179
195
TEST_19
—
—
Not used for the transmitter
180
196
TEST_20
—
—
Not used for the transmitter
181
197
TEST_21
—
—
Not used for the transmitter
182
198
TEST_22
—
—
Not used for the transmitter
183
199
TEST_23
—
—
Not used for the transmitter
184
200
TEST_24
—
—
Not used for the transmitter
185
201
TEST_25
—
—
Not used for the transmitter
186
202
TEST_26
—
—
Not used for the transmitter
187
203
TEST_27
—
—
Not used for the transmitter
188
204
TEST_28
—
—
Not used for the transmitter
189
205
TEST_29
—
—
Not used for the transmitter
190
206
TEST_30
—
—
Not used for the transmitter
191
207
TEST_31
—
—
Not used for the transmitter
9.3 LCD Transducer Block
Relative
Index
Index
Parameter
Write
Mode
Valid
Range
Initial Value
Explanation
0
16
BLOCK_OBJECT
—
—
—
Information on this block such as Block Tag, DD
Revision, Executiion Time etc.
1
17
ST_REV
—
0
The revision level of the static data associated
with the function block. The revision value will be
incremented each time a static parameter value in
the block is changed.
2
18
TAG_DESC
AUTO
Space
The user description of the intended application of
the block.
3
19
STRATEGY
AUTO
0-65535
0
The strategy field can be used to identify grouping
of blocks. This data is not checked or processed by
the block.
4
20
ALERT_KEY
AUTO
0-255
0
The identification number of the plant unit. This
information may be used in the host for sorting
alarms, etc.
5
21
TARGET_MODE
AUTO
AUTO
Set the Target of block mode (MODE_BLK) to Auto,
Man or O/S according to the write Mode of the
parameter to be set or changed.
6
22
MODE_BLK
—
—
AUTO
The mode parameter is a structured parameter
composed of the actual mode, the normal mode,
and the permitted mode.
7
23
ALARM_SUM
—
—
—
The current alarm status associated with the
function block
8
24
DISPLAY_SEL
AUTO
0x00-0x0F 0x01
(DISPLAY1
ON)
Selection of display 1 to 4 to be shown on LCD
Bit0=1:DISPLAY1 ON
Bit1=1:DISPLAY2 ON
Bit2=1:DISPLAY3 ON
Bit3=1:DISPLAY4 ON
9
25
INFO_SEL
AUTO
0x00-0x0F 0x06
Selection of items to be displayed
Bit0=1:TAG ON
Bit1=1:PARAMETER ON
Bit2=1:UNIT ON
Bit3=1:STATUS ON
10
26
BLOCK_TAG1
—
—
AI1
Block tag which includes a parameter to be
displayed on display1
11
27
PARAMETER_SEL1
AUTO
—
0x010A: AI1.
OUT
Selection of a parameter to be displayed on
display1. Select a parameter from Table
12
28
DISPLAY_TAG1
AUTO
Space
Name of block tag to be displayed on display1; up to
six alphanumeric plus a slash[/] and a period [.]
