WATLOW Series 988 User’s Manual 4.33 Setup Menus, Chapter 4
Setup-Output
Retransmit High Limit
Select the high limit for the retransmit signal at output 3.
• The default value is equal to [`rH1] or [`rH2] (in the Input Menu)
depending on whether [Aout] is set to [Prc1] or [Prc2].
• The decimal precision of [ACAL] is determined by [dEC1] (Input Menu) if
[Aout] is set to [Prc1] or [StPt]; it is determined by [dEC2] if [Aout] is
set to [Prc2].
[A`rH] This prompt appears only on controllers equipped with retransmit
hardware (98_ _-_ _ _ _-M_ _ _ or 98_ _-_ _ _ _-N_ _ _) and with [Aout] not
set to [``no].
[A`rL] … [9999]
[A`rH] [A`rH]
Retransmit Calibration Offset
Select an offset value for the retransmit signal at output 3.
• The decimal precision of [ACAL] is determined by [dEC1] (Input Menu) if
[Aout] is set to [Prc1] or [StPt]; it is determined by [dEC2] if [Aout] is
set to [Prc2].
[ACAL] This prompt appears only on controllers equipped with retransmit
hardware (98_ _-_ _ _ _-M_ _ _ or 98_ _-_ _ _ _-N_ _ _) and with [Aout] not
set to [``no].
If Default
↓ ↓
[``°F] [-999] … [```0] … [`999]
[`C_F] [ACAL] [ACAL] [ACAL]
(Global Menu)
[``°C] [-555] … [```0] … [`555]
[`C_F] [ACAL] [ACAL] [ACAL]
(Global Menu)
[-999] … [```0] … [`999] units
a process input [ACAL] [ACAL] [ACAL]
is selected
[A`rH]
˜
NOTE:
See
Chapter 8 for
more information
on retransmit.
[ACAL]
