WATLOW Series 988 User’s Manual

4.29

Setup Menus, Chapter 4

Setup-Output

Alarm 4 Side

Select what triggers alarm 4.

• [both] triggers an alarm when the signal

≤

[A4LO] or

≥

[A4HI].

• [HiGH] triggers an alarm when the signal

≥

[A4HI].

• [LOW] triggers an alarm when the signal

≤

[A4LO].

[A4Sd] This prompt appears only on controllers equipped with output 4
hardware for a relay (98_ _-_ _ _ _-_B_ _, 98_ _-_ _ _ _-_D_ _ ,
98_ _-_ _ _ _-_E_ _ or 98_ _-_ _ _ _-_K_ _) or switched dc (98_ _-_ _ _ _-_C_ _)
and with [`Ot4] set to [`AL4] or [AL4n].

Default

↓

[BOTH]

[HIGH]

[LOW]

[A4SD]

NOTE:
See

Chapter 7

for

more information
on alarms.

[A4Sd]
