Watlow Series 988 - Manual (Page 20)

20
19
T3
T1
T2
Phase
dot
3-phase using 2 current transformers
Figure 2.10b —
Current Transformer Input
98 _ _ - _ 4 _ _ - _ _ _ _
The current transformer must be pur-
chased separately. See Appendix for
Watlow current transformer part
numbers.
Systems that use more than 50 Amps
need an interstage transformer. For
example, if you use a 300A current
transformer, part #16-0073, and an
interstage transformer, part #16-
0176, the 300A current transformer
provides a 5A signal to the interstage
transformer. In turn, the transformer
sends a 20mA maximum signal to the
controller.
2.10 WATLOW Series 988 User’s Manual Installation and Wiring, Chapter 2
Input 2 Wiring
Figure 2.10c —
Digital Event Input 2
98 _ _ - _ 5 _ _ - _ _ _ _
open 0-3VÎ (dc) Event Input 2 off
closed 14-36VÎ (dc) Event Input 2 on
20
19
L2
L1
CT
Load wire
Center leg not used
Single-phase
Figure 2.10a —
Slidewire Feedback or Potentiometer Input
98 _ _ - _ 3 _ _ - _ _ _ _
19
20
18
CW
CCW
Wiper
NOTE:
See
Chapter 8 for
information on
slidewire feedback.
20
18
+5V Î (VDC)
100 Ω
750 Ω
4.7K Ω
1K Ω .01 µ f
19
Internal Circuitry
˜
NOTE:
A process output
cannot be installed
on output 1 when
using a current
transformer input.
20
18
20
19
+
-
NOTE:
Successful installa-
tion requires five
steps:
• Model number and
software choice
(
Appendix );
• DIP switch set-
tings (
Chapter 1 );
• Sensor match
(
Chapter 2 and
Appendix );
• Sensor installation
(
Chapter 2 ); and
• Wiring ( Chapter 2 ).
